ABB laser welding robot

Model Features

The laser beam of the fiber laser is extremely narrow, resulting in a small heat-affected zone and minimal workpiece deformation. Moreover, the welding speed is very fast；

The weld seams are smooth and aesthetically pleasing. After welding, no further treatment is required or only a simple process is needed；

The lifespan of the fiber laser is over 100,000 hours. It has no consumables and requires minimal maintenance, making it very convenient；

The laser efficiency is ≥ 35%, and the equipment is more energy-efficient and power-saving；

The red light indicates the combination of CCD monitoring and observation system, allowing for clear observation of the welding position and welding effect.；

Fiber laser multi-mode welding can freely switch between modulation and continuous modes according to product requirements；

It adopts a self-configured cooling system, using circulating water for cooling. No external cold water supply is required. It also has an alarm function；

The renowned six-axis robot has high precision in repetitive positioning, high accuracy in trajectory operation, and stable operation；

Robots possess great flexibility and can perform flexible, non-contact welding on difficult-to-reach precise parts. They can also adapt to various different welding methods for different complex products；

The welding efficiency is 2 to 10 times that of traditional manual welding.

Robot brand：

International brands (such as ABB, Fanuc, KUKA, Yaskawa, etc.)

Matching gun heads: Straight welding head, Swing welding head, Mirrored welding head

Optional equipment：

Visual system positioning

Wire feeding system

Weld seam tracking system

Reconfigurable machines, etc.
